433MHz Receiver Shield for Arduino

This product is currently sold out.
Tell me when it's back in stock

$39.95

This product has been superseded by the Receiver Shield 315MHz / 433MHz. Click here for the new model.
This page is left for reference only, and this version is no longer being produced.

433MHz wireless connections are very commonly used by consumer electronics including weather stations, home automation remote controls, power consumption meters, car alarms, and also many DIY projects. The “Weather Station Receiver” project in the book “Practical Arduino” shows how to intercept the signals from a La Crosse weather station and decode them using an Arduino.

This fully pre-assembled shield implements the receiver circuit from the book, allowing you to just plug it in and start receiving data straight away. Even the headers are pre-fitted so you can be receiving data in no time!

Features

  • Fully pre-assembled.
  • 433MHz “RXB6” receiver module with the data connection wired to Arduino pin 8 to allow signal timing analysis.
  • Header pin for connecting antenna wire.
  • Red and green debugging LEDs to display signal reception status.
  • Red and green general-purpose surface-mount LEDs with current limiting resistors.
  • Reset button wired through to Arduino reset pin.
  • Blue “power” LED to show when the Arduino is supplying power to the shield.
  • Significant prototyping area where you can add your own parts.
  • Clearly marked GND and 5V rails beside prototyping area.
  • Clear overlay markings on both the top and the bottom! Makes it easy to solder connections on the bottom without having to keep turning it over to check the position of parts.
  • Gold-plated surface: solders easily and very resistant to finger oil, etc.
  • 2 × 100nF power supply smoothing capacitors pre-fitted.
